BS-20BA

 85,00 Excl. BTW

Two-way speaker (4+1"), 20 W RMS (20, 10, 5 & 2.5 W), 100 V & 8 ohms. Black ABS

Categorieën: , Tag:

Description

BS-20BA

Two-way speaker (4+1″), 20 W RMS (20, 10, 5 & 2.5 W), 100 V & 8 ohm. ABS black.

Two-way speaker with power rating of 20 W (selectable by rear switch to 10, 5 and 2.5 W), 100 V line. Connection of low impedance 8 ohms. 4″ speaker for low and medium frequencies and 1″ tweeter speaker for high frequencies. Frequency response of 100-20.000 Hz. Sensitivity 89 dB (1 W, 1 m and 1 kHz). Maximum sound pressure level 102 dB (20 W, 1 m and 1 kHz). Dimensions 170 x 215 x 150 mm. Weight 2.2 kg. Trapezoidal enclosure to improve directivity, black ABS, metallic grille and steel mounting bracket for wall or ceiling.

Speaker                             woofer 4’’ + tweeter 1’’

RMS power                       20 W

Power selection               20, 10, 5 & 2.5 W (100 V) | 20 W (8 Ω)

Frequency response       100 ~ 20,000 Hz

SPL 1 m, 1 kHz                  89 dB (1 W), 102 dB (20 W)

Dimensions (mm)           170 x 215 x 150mm

Weight                               2.2 kg

Finish                                 ABS black (BA) o white (WA)
